Engine

No. cylinder

4 in line

CC (x1.7 if turbocharged)

1972 (3352)

Bore / Stroke (mm)

85.4 / 86

Comp. Ratio

8.5:1

Max.Power (bhp)

300

Revs.

5700

Max.Torque (kg/m)

52

Revs.

4000

Induction

Denso EFI

Turbo

Toyota CT20

No. Valves

16

No. + Position Cams

2 Overhead Camshaft

Location

Front-Transverse

Transmission

Location

4WD

Differential (Front-Central-Rear)

Active-Active-Active

Clutch (Manufacturer)

Carbon (AP) 3 plate

Gearbox (Manufacturer)

6 speed sequential (Xtrac)

Brakes

Front / gravel

DV295

Front / asphalt

DV328/343

Rear / gravel

DV295

Rear / asphalt

DV295

Suspension (shock absorbers)

Front

McPherson (Öhlins)

Rear

McPherson (Öhlins)

Dimensions

Length (mm)

4100

Widht (mm)

1770

Height (mm)

1385

Wheelbase (mm)

2465

Front track (mm)

1564

Rear track (mm)

1556

Weight (kg)

1230

Date 1st Homologation

1.8.1997

1st Major Rally

Mänttä 200 Rally in Finland 1997

1st WRC Event

Finland 1997

WRC Wins (4)

Monte Carlo 1998 (Sainz)

Spain 1998 (Auriol)

New Zealand 1998 (Sainz)

China 1999 (Auriol)
