Engine |
|
No.
cylinder |
4
in line |
CC
(x1.7 if turbocharged) |
1998
(3397) |
Bore
/ Stroke (mm) |
84
/ 90 |
Comp.
Ratio |
9,2:1 |
Max.Power
(bhp) |
300 |
Revs. |
|
Max.Torque
(kg/m) |
55 |
Revs. |
|
Induction |
Hyundai
Pectel |
Turbo |
Garrett |
No.
Valves |
16 |
No.
+ Position Cams |
2
Overhead Camshaft |
Location |
Front-Transverse |
Transmission |
|
Location |
4WD |
Differential
(Front-Central-Rear) |
Active-Active-Mechanical |
Clutch
(Manufacturer) |
Carbon
(AP) 2 plate |
Gearbox
(Manufacturer) |
6
speed sequential (Xtrac) |
Brakes |
|
Front
/ gravel |
DV304 |
Front
/ asphalt |
DV370 |
Rear
/ gravel |
DV304 |
Rear
/ asphalt |
DV355 |
Suspension
(shock absorbers) |
|
Front
|
MacPherson
(Öhlins) |
Rear |
MacPherson
(Öhlins) |
Dimensions |
|
Length
(mm) |
4200 |
Widht
(mm) |
1770 |
Height
(mm) |
1332 |
Wheelbase
(mm) |
2440 |
Front
track (mm) |
1550 |
Rear
track (mm) |
1550 |
Weight
(kg) |
1230 |
Date
1st Homologation |
1.1.2000 |
1st
Major Rally |
Swedish
Rally 2000 |
Debut:
Accent WRC2 |
Portugal
2001 |
Debut:
Accent WRC3 |
Corsica
2002 |
Best
WRC Result |
4th
Australia 2000 (Eriksson) |
|
4th
Great Britain 2001 (McRae) |
