Engine

No. cylinder

4 in line

CC (x1.7 if turbocharged)

1997 (3395)

Bore / Stroke (mm)

85 / 88

Comp. Ratio

8.5:1

Max.Power (bhp)

300

Revs.

6000

Max.Torque (kg/m)

55

Revs.

3500

Induction

ECI Multi Injection

Turbo

Mitsubishi

No. Valves

16

No. + Position Cams

2 Overhead Camshaft

Location

Front-Transverse

Transmission

Location

4WD

Differential (Front-Central-Rear)

Active-Active-Active

Clutch (Manufacturer)

Carbon (AP) 3 plate

Gearbox (Manufacturer)

6 speed sequential (Xtrac)

Brakes

Front / gravel

DV310

Front / asphalt

DV368

Rear / gravel

DV280

Rear / asphalt

DV280

Suspension (shock absorbers)

Front

McPherson (Öhlins)

Rear

Multi-link+Coil (Öhlins)

Dimensions

Length (mm)

4350

Widht (mm)

1770

Height (mm)

1395

Wheelbase (mm)

2510

Front track (mm)

1530

Rear track (mm)

1525

Weight (kg)

1230

Date 1st Homologation (number)

1.1.1997

1st Major Rally

Monte Carlo 1997

Debut: Lancer Evolution V

Catalunya 1998

Debut: Lancer Evolution VI

Monte Carlo 1999

Debut: Lancer Evolution 6.5

Monte Carlo 2001

WRC Wins (19)

Portugal 1997 (Mäkinen)

Spain 1997 (Mäkinen)

Argentina 1997 (Mäkinen)

Finland 1997 (Mäkinen)

Sweden 1998 (Mäkinen)

Kenya 1998 (Burns)

Argentina 1998 (Mäkinen)

Finland 1998 (Mäkinen)

Italy 1998 (Mäkinen)

Australia 1998 (Mäkinen)

Great Britain 1998 (Burns)

Monte Carlo 1999 (Mäkinen)

Sweden 1999 (Mäkinen)

New Zealand 1999 (Mäkinen)

Italy 1999 (Mäkinen)

Monte Carlo 2000 (Mäkinen)

Monte Carlo 2001 (Mäkinen)

Portugal 2001 (Mäkinen)

Kenya 2001 (Mäkinen)
