Engine

No. cylinder

4 in line

CC (x1.7 if turbocharged)

1993 (3390)

Bore / Stroke (mm)

90.8 / 76.9

Comp. Ratio

8,5:1

Max.Power (bhp)

300

Revs.

5800

Max.Torque (kg/m)

51

Revs.

3500

Induction

Ford F8

Turbo

Garrett T4

No. Valves

16

No. + Position Cams

2 Overhead Camshaft

Location

Front-Longitudinal

Transmission

Location

4WD

Differential (Front-Central-Rear)

Active-Active-Mechanical

Clutch (Manufacturer)

Carbon (AP) 3 plate

Gearbox (Manufacturer)

6 or 7 speed (Ford)

Brakes

Front / gravel

DV315

Front / asphalt

DV378

Rear / gravel

DV315

Rear / asphalt

DV313

Suspension (shock absorbers)

Front

McPherson (Bilstein)

Rear

Semi Trailing Arm (Bilstein)

Dimensions

Length (mm)

4211

Widht (mm)

1734

Height (mm)

1425

Wheelbase (mm)

2550

Front track (mm)

1453

Rear track (mm)

1472

Weight (kg)

1230

Date 1st Homologation (number)

1.1.1993

1st Major Rally

Monte Carlo 1993

WRC Wins (8)

Portugal 1993 (Delecour)

Corsica 1993 (Delecour)

Greece 1993 (Biasion)

Italy 1993 (Delecour)

Spain 1993 (Delecour)

Monte Carlo 1994 (Delecour)

Finland 1994 (Mäkinen)

Indonesia 1996 (Sainz)
